second-hand CA6132 lathe
The second – hand CA6132 lathe is a common general – purpose lathe, which is suitable for single – piece, small – batch production, and can process various surfaces such as cylindrical and conical surfaces5.
For second – hand CA6132 lathes, it is necessary to focus on checking the wear of key components, such as the radial and axial run – out of the spindle, and the straightness and wear of the guide rails. At the same time, it is necessary to check whether the lubrication system has oil leakage, whether the electrical system is in good condition, and understand its use history and maintenance records, which will affect the performance and service life of the machine tool.
2,094.00$
The following are its main attributes:
- Basic Machining Parameters1:
- The center height is 175mm, and the maximum swing diameter over bed is 350mm. The maximum swing diameter of the workpiece over the carriage is 180mm.
- The maximum machining length is usually 750mm or 1000mm. The diameter of the bar stock is about 45 - 48mm, and the through - hole diameter of the spindle is 46 - 52mm. The taper hole of the spindle is Morse No. 6.
- Power and Motion Parameters1:
- The main motor power is 3/4.5KW, and the speed range of the spindle is 25 - 1600r/min, with 12 levels of speed regulation, which can meet the processing requirements of different materials and process requirements.
- The maximum longitudinal travel of the carriage is about 650mm (for a 750mm machining length model). The longitudinal feed rate is 0.04 - 2.16mm/r, with 138 kinds; the transverse feed rate is 0.02 - 1.08mm/r, also with 138 kinds.
