- Technical Parameters10
- Worktable Size: Usually 1700mm×400mm, with a T - slot width of 18mm and a maximum load of 800kg, which can meet the processing needs of larger workpieces.
- Worktable Stroke: The longitudinal stroke is 900mm (manual) / 880mm (power - driven), the transverse stroke is 315mm, and the vertical stroke is 385mm (manual) / 300mm (power - driven), which can process workpieces of different sizes.
- Spindle Parameters: The spindle speed range is 30 - 1500r/min, with 18 speed levels, which can meet the cutting requirements of different materials and processing technologies. The spindle axial movement distance is 85mm, and the vertical milling head can rotate ±45° in the vertical plane, expanding the processing range.
- Power: The main - drive motor power is 11kW, which can provide sufficient power for heavy - duty cutting.
- Overall Dimensions and Weight: The overall dimensions are about 2556mm×2159mm×2298mm, and the machine weight is about 4200kg. The casting structure of high - quality cast iron ensures the stability of the machine during operation.
