X6336 milling machine, vertical and horizontal

X6336 milling machine, vertical and horizontal - Image 2

X6336 milling machine, vertical and horizontal - Image 3

Advantages

Strong Heavy-Duty Cutting Capacity: With a high-power motor and rigid structure, it can perform deep cutting and heavy-load processing on large workpieces, improving material removal efficiency.
High Processing Precision: The precision spindle, ball screw transmission (in advanced models), and stable worktable ensure high accuracy, with flatness within 0.03mm/1000mm and perpendicularity within 0.02mm/300mm, meeting strict assembly requirements.
Large Processing Range: The large worktable and long travel distances allow processing of large or long workpieces, reducing the need for multiple setups and improving processing efficiency.
Versatile and Adaptable: Compatible with various accessories (dividing heads, rotary tables, indexing plates), enabling processing of complex parts such as gears, cams, and helical grooves, suitable for diverse processing needs.
Durable and Reliable: High-quality materials and precision manufacturing ensure a long service life. Second-hand machines, after proper maintenance, can maintain stable performance for years, offering high cost-effectiveness.

3,673.00$

The X6336 milling machine adopts a horizontal layout, with the spindle axis parallel to the worktable, which is suitable for horizontal milling operations such as milling planes, grooves, and gears. It is upgraded based on traditional horizontal milling machines, with enhanced structural rigidity and transmission efficiency. It can process a wide range of materials, including high-strength alloy steel, cast iron, and large-sized carbon steel workpieces, and supports multi-station continuous processing with the help of accessories like dividing heads and rotary tables. The machine body is made of high-grade cast iron, subjected to double aging treatment (natural and artificial) to eliminate internal stress, ensuring minimal deformation even under long-term heavy loads and maintaining stable processing accuracy.

Specific Attribute	Detailed Description
Equipment Type	Horizontal universal milling machine (heavy-duty, high-precision)
Core Function	Heavy-duty milling, precision processing of large/complex parts; supports grooves, planes, gears
Operation Features	Heavy-duty cutting capability, large worktable, manual/semi-automatic operation
Worktable Dimensions	Approximately 1600mm×360mm (length×width)
Spindle Speed Range	30-1800r/min (18 adjustable speed levels)
Worktable Travel	Longitudinal: up to 800mm; Transverse: up to 360mm; Vertical: up to 400mm
Feed Rates	0.05-5mm/r (mechanical); 0.01mm/r (servo, optional)
Maximum Processing Capacity	Milling width up to 360mm (steel); suitable for large parts and batch processing
Main Motor Power	7.5kW
Overall Dimensions	Approximately 2500mm×1800mm×2200mm (length×width×height); net weight: ~3500kg
Bed and Column	Thickened cast iron, box-type structure, double aging treatment, high rigidity
