XA5032 Heavy-duty universal second-hand milling machine

XA5032 Heavy-duty universal second-hand milling machine - Image 2

XA5032 Heavy-duty universal second-hand milling machine - Image 3

XA5032 Heavy-duty universal second-hand milling machine - Image 4

XA5032 Heavy-duty universal second-hand milling machine - Image 5

The XA5032 Heavy-duty Universal Second-hand Milling Machine is a classic medium-sized universal milling equipment widely used in mechanical processing. It is favored for its strong rigidity, wide processing range, and stable performance, and is still a common choice in second-hand markets for small and medium-sized enterprises or workshops.

Application Fields

It is widely used in machinery manufacturing, mold processing, automobile parts, and hardware production, suitable for processing:

Ferrous metals (carbon steel, alloy steel, cast iron)
Non-ferrous metals (aluminum, copper alloys)
Workpieces such as shafts, plates, brackets, and mold blanks

2,357.00$

Attribute	Details
Distance from Spindle End Face to Worktable	60–410mm
Distance from Spindle Centerline to Vertical Guide Rail of Bed	350mm
Spindle Hole Taper	7:24 ISO50
Spindle Hole Diameter	29mm
Spindle Speed	30–1500r/min, 18 levels
Maximum Swivel Angle of Vertical Milling Head	±45°
Spindle Axial Movement Distance	85mm
Worktable Surface Size	1325×320mm (some models are 1600×320mm)
Worktable Stroke (Manual / Power - driven)	Longitudinal: 720/700mm (900/880mm for some models); Transverse: 255/240mm; Vertical: 370/350mm (440/430mm for some models)
Worktable Feeding Range (mm/min)	Longitudinal: 23–1180mm/min; Transverse: 15–765mm/min; Vertical: 15–765mm/min
Main Motor Power	7.5kW
Feed Motor Power	1.5kW
Overall Dimensions (Approx.)	2294×1899×1820mm (Length×Width×Height, may vary slightly by model)
Net Weight (Approx.)	2800–3200kg (depending on configuration and accessories)
